FHD18 Series MTP-12 Cassette, 12 Fibers OS2 Singlemode, MTP to 3x LC Quad (Green), 0.35dB Max


MTP/MPO fiber cassette is a convenient plug and play cable management solution that improve cabling manageability. Each fiber cassette will be pre-installed with factory-terminated and factory-tested 12 fiber MTP/MPO assembly, with assured quality on optical loss performance. This fiber cassette can be flexibly integrated into our FHD18 series rack mount patch panels, which support quick installation and reliable cable management.

MTP (MPO) Cassettes is ideal high density solution for 1G, 10G, 25G LC duplex networking transmission. Our MTP cassette systems is designed according to internationally recognised standards and so when used with standard duplex patch cords will enable a connection between SFP or SFP+ ports within active equipment.

High density & Plug-&-play cassette modules
- Mounts up to 144-fiber per 1U, 576-fiber per 4U rackmount patch panel
- Flexible for integration with 1U/2U/4U FHD18 series rack-mount patch panel
Ease of installation and good traceability
- Channel label and data label printed with insertion loss value for each port
Qualified performance beyond TIA/EIA and IEC standards
- Pre-installed with factory-terminated and factory tested MTP/ MPO to LC hydra assembly
Simple to use, convenient installation
- Pre-installed with fiber MTP/MPO adapters at the rear, and LC adapters in the front panel
Field terminations Elimination
- Reduces labour cost and improves cabling manageability

Product Specification

Fiber Count 12 Fibers Fiber Mode OS2 9/125um
Front Connector Type 3 LC APC Quad (Green) Rear Connector Type 1x MTP Base-12 Male (Pinned)
MTP® Adapter Key up to Key down Performance Level Laser Optimized
Insertion Loss MTP®≤0.35dB, LC≤0.2dB Return Loss MTP≥60dB, LC≥50dB
RoHS Compliancy Status Compliant Dimensions (HxWxD)  90mm×130mm×11.7mm
Operating Temperature -10°C to 60°C Storage and Shipping Temperature -10°C to 60°C
