8K HDMI 2.1 48Gbps 60Hz 100% Pure Optical Fiber Cable w/ Detachable MPO Connectors
- Set of 2x HDMI 2.1 terminations included, Source and Display.
- Set of 2x MPO adapters/couplers included for "snap on" connections.
- in-wall MPO-MPO Fiber Optic Cables up to 1000ft as options.
This detachable optical pure fiber 8K HDMI2.1 cable is different from the conventional optical fiber HDMI cable, it has innovative performance such as non-directional installation, detachable conversion head, non-destructive and non-radiation, etc.
It use only Optical Fiber Cable without any copper and adopts advanced Texas Instruments chip, thus features Slim/Portable/Long distance as the cable diameter is only 3.0mm and max length is 333m (1000ft).
- Installs in two clicks on ANY MPO/MTP fiber optic cable, hassle free, no tools required.
- 4K@120Hz / 8K@60Hz / 10K@30Hz
- 48 Gbps and above
- UNCOMPRESSED for true viewing experience.
- 2m (6.56ft) long HDMI fiber terminals for extended reach (no need for patch cords to wall plate).
- Works with any fiber optic 12 strand MPO/MTP terminated
Why Choose 100% pure fiber MPO fiber optical HDMI cable?
Normally, the HDMI AOC cables are already called as an optical fiber HDMI cable. Let’s ignore the name disputes. It does use optical fiber cables, but it still uses copper core cables at the 7 low-frequency points, so it is correct to say as a hybrid optical fiber cable; of course, due to the characteristics of optical fiber, the problem of signal attenuation caused by long-distance transmission of audio and video signals is greatly reduced.
The standard fiber optic cable specifications can be certified by color, and the aqua color represents the 10GB, 50/125µm multi-mode fiber optic cable. The high-bandwidth, long-distance transmission, low attenuation, and small wire diameter of optical fiber are definitely the most reliable, durable and safest signal transmission wires. As we know, the long-distance transnational transmission is also based on submarine optical fiber cables. In our industry, since the optical fiber is an insulator, the signal will not be affected by electromagnetic interference and can be installed next to any industrial or digital equipments. And our HDMI pure optical fiber cable can make computer signals can be transmitted stably up to 1000ft and friendly support for most graphics cards for both guests and hosts.
MPO (Multi-fiber Pull On) is the first generation of shrapnel clamping multi-core optical fiber connector designed by NTT Communications Corporation of Japan. It uses a mechanical tenon as a relay connection between the optical fiber cable and the signal terminal. Taking the armored pure optical fiber cable we use as an example, it is easy to shuttle through any pipeline with a wire diameter of only 3mm, but it is necessary for the constructor to connect the opposite terminal that can transmit signals normally after the wire is threaded. MPO is extremely important. Compared with the traditional bulky HDMI cable head, the MPO fiber optic connector is only 12.6mm wide by 7.6mm high. For our engineering units, it does strive for greater space for threading flexibility.
