12G SDI Video Optical Fiber Camera System for EFP ENG Live Transmission
Fiber Camera System 12G SDI Video Optical Converter for EFP ENG Live Transmission
This 12G-SDI Advanced EFP Fiber System allows transmission of one 12G SDI video with local loop out from the camera to the base station.
This setup provides high-quality, uncompressed, and delay-free signal extension up to 10km.
12G SDI EFP fiber transmission system built-in serial clock recovery,signal equalization and line drive,input automatic detection signal 12G SDI/6G-SDI/3G-SDI/HD-SDI/SDI/ASI, compatible with SMPTEST2082-1 (12GUHD-SDI), ST2081-1 (6GUHD-SDI), SMPTE424M, SMPTE292M, SMPTE259M, SMPTE297M, SMPTE305M, SMPTE310M standards.
Product Features
- Support ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G), ST-292 (HD) and ST-259 (SD); compatible with DVB-ASI and AES10 (MADI)
- Both transmitter and receiver have clock recovery function; (clock restorer can reduce high frequency jitter and completely regenerate data with pure low jitter clock)
- The clock restorer is locked to 11.88Gbps, 5.94Gbps, 2.97Gbps, 1.485Gbps or 1.001 frequency division sub rate and SMPTE rate of 270Mbps
- Signal input has automatic cable equalization (EQ) function, output has drive (CD) function
- Support 1/4 hot shoe screw
- Support plug and play SFP optical module, which can replace optical module corresponding to different distances or interfaces according to the actual site requirements
- Support single-mode single-fiber/dual-fiber transmission distance 10km (default)
- Support status light display
- Plug and play, without debugging
